Hot sale Ridging plough for ridging

Advantages:

l The disc blades are made after the heat treatment in the material of 65Mn  spring steel.

l There two series of this disc ridger. Two discs and four discs respectively. You can choose the nos of disc to meet your need.


  Contact Now
Product Details

3Z series of disc ridger is suitable for ridging after the tillage in the farm field. it consists of heavy duty tubular box frame, 3 point hitch system and discs.the disc blades are made after the heat treatment in the material of 65 Mn spring steel that has better hardness. The machine is reasonable for construction ,conveniently to transport, easy to adjust, and conveniently to use and maintain .

Model

unit

3Z-80

3Z-120

3Z-140

3Z-180

3Z-260

Working width

mm

800

1200

1400

1800

2600

Ridging width

mm

200~450

300-500

Ridging height

mm

150-260

150~300

Ridging of rows


1(2)

1(2)

1

1(2)

1(2)

Total weight

kg

120

140

220

200

246

Matched power

hp

20~30

30-40

50-60

60-70

70-90

Linkage


Three-point suspension I type

Three-point suspension II type


Product form
